| Battery Parameters | |
|---|---|
| Battery Type | LFP |
| Cell Model | 306Ah |
| Energy Storage Capacity | 109kWh |
| Cycle Life (45℃, 60%SOH, 0.5P) | ≥10000 |
| Maximum Charge/Discharge Rate | ≤0.5P |
| Enclosure Protection Rating | IP67 |
| AC Output (Grid/Off-Grid) | |
| Rated Output Power | 50kW |
| Rated Output Voltage | 380/400Vac |
| Rated Output Frequency | 50/60Hz |
| Total Current Harmonic Distortion (THD) | < 3% |
| Total Voltage Harmonic Distortion (THD) | < 3% |
| Photovoltaic (PV) Input | |
| MPPT Voltage Range | 150 - 850Vdc |
| Maximum PV Input Power | 96kW |
| Number of MPPT Channels/Number of Strings per Channel | 4/2 |
| Maximum Input Current | 40/40/40/40A |
| General Parameters | |
| Grid/Off-Grid Switching Time | < 20ms |
| Cooling Method | Air Cooling |
| Operating Temperature | -25 - 55℃ |
| Relative Humidity | 0 - 95% (No Condensation ) |
| Operating Altitude | ≤4000m（Rated Capacity Reduction>2000m） |
| Protection Rating | IP54 |
| Dimensions (Width × Depth × Height) | 1272×1356.8×2070mm |
| Weight | ≈18T |
| Certifications | EN 50549-1、EN50549-10、VDE-AR-N 4105、NRS 097-2-1、IEC 61000、IEC 62477、IEC 62619、IEC62109、UN38.3 |
