| Product Model | CT-0125K-0254H-L | CT-0115K-0232H-1 |
|---|---|---|
| Cell Parameters | ||
| Cell Type | LFP | LFP |
| Cell Model | 306Ah | 280Ah |
| Energy Storage Capacity | 254kWh | 232kWh |
| Cycle Life (25℃, 60%SOH, 0.5P) | ≥10000 | ≥8000 |
| Battery Configuration | 1P260S | 1P260S |
| Voltage Range | 728 - 936Vdc | 728 - 936Vdc |
| Maximum Charge/Discharge Rate | 0.5P/0.5P | 0.5P/0.5P |
| Certifications | UN38.3、UL1973、IEC62619、UL9540A、GB36276-2018 | UN38.3、UL1973、IEC62619、UL9540A、GB36276-2018 |
| AC Parameters | ||
| Rated Output Power | 125kW | 115kW |
| Grid Voltage | 380/400Vac@50Hz | 380/400Vac@50Hz |
| Auxiliary Power Supply(kW) | 4 | 4 |
| Power Factor | -1~+1 | -1~+1 |
| Certifications | GB34120 | GB34120 |
| General Parameters | ||
| Cooling Method | Liquid Cooling | Liquid Cooling |
| Communication Model | Ethernet | Ethernet |
| Operating Temperature | -20~55℃（Rated Capacity Reduction>45℃） | -20~55℃（Rated Capacity Reduction>45℃） |
| Relative Humidity | 0~95%（No Condensation） | 0~95%（No Condensation） |
| Operating Altitude | ≤4000m（Rated Capacity Reduction>2000m） | ≤4000m（Rated Capacity Reduction>2000m） |
| Fire Safety System | Precision Fire Safety（Up to Enclosure Level） | Precision Fire Safety（Up to Enclosure Level） |
| Operating Temperature Range (International Conditions, 0.5P) | ≤4℃ | ≤4℃ |
| Enclosure Protection Rating | IP67 | IP67 |
| Dimensions (Width × Depth × Height) | 980×1700×2350mm | 980×1700×2350mm |
| Weight | ≈3.0T | ≈3.0T |
